- 【Tried-and-True Safe Guard】This one-stop security solution includes 8pcs 1080p wired cameras & 8CH 3K Lite DVR that works with TVI, AHD, CVI, CVBS & IP cameras. The DVR can hook up with 3K/5MP@20fps cams or 1080P@30fps ones. Plus, the advanced sensor & smart IR capture clear images up to 100ft away.
- 【AI Motion Detection 2.0】Driving AI to the next level, human&vehicle detection, line crossing, or region entrance detection are more accurate than before. For quicker locating in crucial moments, human&vehicle smart searching in recordings offers you great help.
- 【H.265 for Smoother & Longer Recording】Upgraded to H.265 , the recording time is lengthened, and the bandwidth is lessened. And an included 4TB hard drive saves you extra expense. (Support up to 10TB HDD, package comes with 4TB HDD.)
- 【Outdoor IP67 Waterproof】The IP67 weatherproof housing enables the camera to work perfectly even in super cold or low-temperature environments, even from -40°F to 140 °F. You can install the cameras outdoors or indoors, just anywhere you like, without worrying about rain or shine.
- 【24/7 Peace of Mind】Whenever real threats are detected, immediate pushes pop up on your phone, and you can check it out via 3G/4G/5G/Wi-Fi. However far away you are from home, this reliable security system secures your peace of mind day&night.
DVR Specification:
Up to 3K high definition live viewing
Up to 3K Lite recording & playback
Advanced H.265 Video Compression
Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
Supports iPhone、iPad、Android mobile remote monitoring
Deep learning based human and vehicle targets classification of Motion Detection 2.0 for all analog channels
Quick search by object or event type
Video Compression: H.264 /H.264/H.265/H.265
Video Input: 16CH Analog HD/Analog 2CH IP Video (up to 24 channel when IP enhanced mode on)
Video Output: HDMI and VGA Up to 1080P
Audio Input: 1-ch RCA, 16-ch via coaxial cable
Audio Output: 1-ch RCA
Supported Camera Types: "Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP;
Support AHD Input: 4MP, 1080p;
Support CVI Input: 4MP, 1080p;
Support CVBS Input;
Support IP Video Input：6MP/5MP/4MP/3MP/1080P/720P"
Analog HD Playback Resolution: 3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps
IPC Playback Resolution: Up to 6MP
Max Playback Channel: 4-ch
Motion Detection 2.0: All analog channels support human and vehicle detection to reduce false alarm
HDD: 1 SATA interface
HDD Capacity: Up to 10TB capacity
Camera Specification:
. 5MP HD TVI bullet Security Camera
. HD analog output, up to 5 MP resolution
. Clear day and night vision with auto IR-cut
. Up to 100ft night vision with Smart IR
. IP67 Dust and Waterproof Rating
Image sensor: 5MP CMOS Image sensor
Video Resolution: 2560 (H) × 1944 (V)
Frame Rate: "PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps
NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps"
Lens: 2.8mm
Angle of View: 85.5°
Number of Infra-Red LEDs: 2
Night Vision Distance: Up to 100ft/30m
DNR: 2D DNR
Wide Dynamic Range: Digital WDR
Video Output: HD BNC×1
Operating Power: DC 12V
Operating Temperature: -40 °F – 140 °
