Camera
Image Sensor:1/2.7" Progressive Scan CMOS
Max. Resolution:3840 × 2160
Min. Illumination:Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
Shutter Time:1/3 s to 1/100,000 s
Day & Night:IR cut filter
Angle Adjustment:Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lens
Lens Type:Fixed focal lens, 2.8 mm
Focal Length & FOV:2.8 mm, horizontal FOV 113°, vertical FOV 62°, diagonal FOV 134°
Lens Mount:M12
Iris Type:Fixed
Aperture:F2.0
DORI:2.8 mm, D: 79 m, O: 31 m, R: 15 m, I: 7 m

Illuminator
Supplement Light Type:IR,White Light
Supplement Light Range:Up to 30 m
Smart Supplement Light:Yes
IR Wavelength:850 nm

Video
Main Stream:50 Hz:12.5 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression:Main stream: H.265 /H.265/H.264 /H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate:32 Kbps to 16 Mbps
H.264 Type:Baseline Profile,Main Profile,High Profile
H.265 Type:Main Profile
Bit Rate Control:CBR,VBR
Region Of Interest (ROI):1 fixed region for main stream
Scalable Video Coding (SVC):H.264 and H.265 encoding

Audio
Audio Type:Mono sound
Environment Noise Filtering:Yes
Audio Sampling Rate:8 kHz/16 kHz
Audio Compression:G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Bit Rate:64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Network
Security:Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Simultaneous Live View:Up to 6 channels
API:Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK
Protocols:TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
User/Host:Up to 32 users;3 user levels: administrator, operator, and user
Client:iVMS-4200,Hik-Connect
Web Browser:Plug-in required live view: IE 10, IE 11;Local service: Chrome 57.0 , Firefox 52.0 , Edge 89

Wide Dynamic Range (WDR):120 dB
SNR:≥ 52 dB
Day/Night Switch:Day,Night,Auto,Schedule
Image Enhancement:BLC,HLC,3D DNR
Image Settings:Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Privacy Mask:4 programmable polygon privacy masks

Interface
Ethernet Interface:1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone:Yes
Reset Key:Yes

Event
Basic Event:Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage:Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture

General
Power:12 VDC ± 25%, 0.41 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection
PoE: IEEE 802.3af, Class 3, max. 6.5 W
Material:Metal & Plastic
Dimension:6.7" × 2.6" × 2.7"
Weight:0.6 lb.
Storage Conditions:-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:English, Ukrainian
General Function:Heartbeat,anti-banding,mirror,password protection,password reset via email
